ITE Adapter UES100LCP2-SPC
Meets communication and medical safety certification
2 MOPP isolation protection
Leakage current ≤ 100μA
Standby power consumption ≤ 0.15W
5V/9V12V/15V/20V output, up to 100W
Working altitude 5000 meters
Interchangeable plug
GAN technology
Complies with USB
PD3.1&PD3.0&QC4.0+&QC3.0&QC2.0 fast charging protocol
Meets home medical standards
DESCRIPTION
The UES100LCP2-SPC is a high-performance 100W I.T.E. wall plug power adapter, delivering 5V to 20V outputs with USB PD3.0 fast charging support. With a universal 90-264VAC input, it ensures DOE Level VI efficiency and ≤0.15W standby power. Certified to IEC 62368-1, it offers robust safety and reliable operation up to 5,000m altitude. Compact with interchangeable AC plugs, it’s ideal for Laptops and Ultrabooks, Test instruments, Professional camera gear, external displays, network devices, and USB-C hubs, providing efficient, versatile, and safe power globally.
Safety&Compliance
Safety Standards – IEC62368,UL62368,EN62368,
Safety Approvals -CB, CE, TUV-Mark, UL
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UES100LCP2-SPC | 100.0 | 80-264 | 5.0 | 0.01-3.00 | 0~+40 | CB, CE, TUV-Mark, UL |
| UES100LCP2-SPC | 100.0 | 80-264 | 9.0 | 0.01-3.00 | 0~+40 | CB, CE, TUV-Mark, UL |
| UES100LCP2-SPC | 100.0 | 80-264 | 12.0 | 0.01-3.00 | 0~+40 | CB, CE, TUV-Mark, UL |
| UES100LCP2-SPC | 100.0 | 80-264 | 15.0 | 0.01-3.00 | 0~+40 | CB, CE, TUV-Mark, UL |
| UES100LCP2-SPC | 100.0 | 80-264 | 20.0 | 0.01-5.00 | 0~+40 | CB, CE, TUV-Mark, UL |
RELATED APPLICATIONS
POPULAR QUESTIONS
If it uses USB-C PD (Power Delivery), the connected device negotiates the correct voltage automatically. For programmable adapters, DIP switches or software control may be used.
Yes. If the device supports USB-C PD or requires lower voltage (like 5V or 9V), the adapter intelligently adjusts output to match it.
Typically certified with CE, UL, FCC, RoHS, and compliant with IEC 62368 and DOE Level VI or ERP energy efficiency standards.
If it has multiple ports or a smart hub design, yes. Otherwise, a single-port adapter can only power one device at a time.
No. The adapter uses a smart protocol (PD) to negotiate the correct voltage. It only outputs what the connected device requests.
Yes, if the adapter allows manual or negotiated 12V output, and the display accepts 12V DC with proper current draw (≤3A).
You need a USB-C to USB-C E-marked cable rated for 5A (100W) to enable full 20V/5A output.
The wall-plug version is intended for portable or desktop use. For fixed installations, consider a desktop or industrial version.
The adapter will limit the output to 100W. Some devices may charge slowly or display a warning. Always use devices within rated specs.
Most 100W wall-plug adapters are fanless with efficient thermal design. High-load operation may cause it to get warm, but it's designed to handle that.
