ITE Adapter UEL036LCP-E1
Wide range of output power with high efficiency
Wide range of AC input voltage 90- 264VAC
Protections against: short circuit/over current/over voltage/over load
Meets 2kV surge immunity
Standardized module, easy to install and maintain
LED load less than 100%
Changeable AC plugs for universal use
Output match DC Jack
DESCRIPTION
The UEL036LCP-E1 is a 36W LED driver with a compact design, compliant with CCC, cULus, CE, and other safety standards. Supporting a 90-264VAC input range, it delivers outputs of 24-48V (0-1.5A) with protections against short circuit, overcurrent, overvoltage, and overload. With 87-88% efficiency, it’s ideal for High-speed scanners， portable logic analyzer, high-end barcode printers, networking equipment, professional audio equipment, and Smart Home Hub.
Safety&Compliance
Safety Approvals – CCC,CE
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UEL036LCP-E1 | 36.0 | 90-264 | 48.0 | 0-0.75 | -10~+40 | CCC |
| UEL036LCP-E1 | 36.0 | 90-264 | 36.0 | 0-1.00 | -10~+40 | CCC |
| UEL036LCP-E1 | 36.0 | 90-264 | 24.0 | 0-1.50 | -10~+40 | CCC |
RELATED APPLICATIONS
POPULAR QUESTIONS
Devices that operate at 24V, 36V, or 48V and draw up to 36W, such as industrial controllers, PoE devices, robotics modules, and professional audio gear.
Yes, as long as the LED strip's power demand is within 36W (e.g., 1.5A at 24V). Ensure correct voltage and polarity before connecting.
Yes. Many passive PoE systems use 24V or 48V power, making this adapter a good match for such applications.
Yes. It includes built-in protections such as OVP (Over Voltage Protection), OCP (Over Current Protection), SCP (Short Circuit Protection), and thermal shutdown.
Yes. When used within rated limits, it is designed for long-term, 24/7 industrial or commercial use.
Not directly. This adapter provides fixed voltage output and lacks CC/CV charging logic. Use it only with a proper battery management or charging circuit.
Most commonly, a 5.5mm x 2.5mm or 2.1mm DC barrel jack, but it can be customized (e.g., aviation plug, Molex, etc.) based on your equipment.
ITE stands for Information Technology Equipment. It means the adapter meets IEC 62368-1 or similar standards for IT and office electronics.
Yes. It supports 100–240V AC input, making it compatible worldwide with the correct plug type (EU, US, UK, AU, etc.).
The output voltage determines the type of device it powers. Higher voltages (36V, 48V) allow for more efficient power delivery over distance and are preferred in professional or industrial applications. Current output decreases as voltage increases, but power remains up to 36W.
