Medical Open Frame Power Supply UES250-XXXYYYSPAZ-OP
Medical Open Frame Power Supply UES250-XXXYYYSPAZ-OP Home Medical Open Frame Power Supply UES250-XXXYYYSPAZ-OP Medical Open Frame Power Supply UES250-XXXYYYSPAZ-OP 48Vdc 2A open frame power supply
36 W
85 ~ 264 Vac input (wide)
9 ~ 54 Vdc output options
0 to +45°C temperature range
No-load power consumption < 0.075W
2 MOPP input to output isolation
4 types of AC inlet
Application place: portable ultrasound diagnostic instrument, EEG electroencephalogram, blue light therapy instrument, urine analyzer, mini centrifuge, medical-grade sleep aid
The UES36C1-SPA is a versatile 36W AC to DC desktop plug-type external switching power supply 12V, designed for healthcare applications. It offers multiple output options, including 5V, 14V, 30V, and 48V. This power supply input ports and adheres to the stringent safety standards of IEC 60601-1 3.1 Edition for 2 x MOPP applications, ISO 13485 Compliant, as well as the 4th Edition EMC requirements, ensuring class II power supply operation. Suitable for a broad range of medical equipment, such as portable ultrasound diagnostic instruments, EEG electroencephalogram, blue light therapy instruments, urine analyzers, mini centrifuges, and medical-grade sleep aids.
Safety Standards – IEC60601,EN60601,UL60601
Safety Approvals – CB, CCC, CE, cULus, FCC, KC, NRTL, PSE, RCM, TUV-GS, TUV-Mark
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UES36C1-SPA | 30.0 | 80-264 | 5.0 | 0.01-6.00 | 0 ~ +45 | CB, CCC, CE, cULus, FCC, KC, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES36C1-SPA | 30.0 | 80-264 | 5.1-5.9 | 0.01-5.00 | 0 ~ +45 | CB, CCC, CE, cULus, FCC, KC, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES36C1-SPA | 36.0 | 80-264 | 7.5-14.0 | 0.01-4.00 | 0 ~ +45 | CB, CCC, CE, cULus, FCC, KC, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES36C1-SPA | 36.0 | 80-264 | 14.1-21.0 | 0.01-2.40 | 0 ~ +45 | CB, CCC, CE, cULus, FCC, KC, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES36C1-SPA | 36.0 | 80-264 | 21.1-30.0 | 0.01-1.63 | 0 ~ +45 | CB, CCC, CE, cULus, FCC, KC, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES36C1-SPA | 36.0 | 80-264 | 30.1-48.0 | 0.01-1.16 | 0 ~ +45 | CB, CCC, CE, cULus, FCC, KC, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
It is suitable for patient monitors, portable ultrasound, ECG machines, nebulizers, blood pressure monitors, and small lab analyzers.
Yes, it can be designed to meet IEC 60601-1 and IEC 60601-1-2 standards for medical electrical safety and EMC.
The adapter supports a wide range from 5V to 48V, covering various medical device requirements.
Absolutely. It is ideal for home-use devices like digital thermometers, pulse oximeters, and sleep therapy equipment.
Various DC plug types (e.g., 2.1mm, 2.5mm), DIN, or custom connectors can be provided depending on the application.
Yes, it can be certified with UL, CE, FCC, UKCA, PSE, and other regional standards upon request.
Yes, options like EU, US, UK, and AU plugs are available for global compatibility.
It meets DOE Level VI or CoC Tier 2 efficiency standards, ensuring energy-saving performance.
Yes, it is designed for 24/7 operation with stable output and over-temperature protection.
It includes OVP (over-voltage), OCP (over-current), SCP (short-circuit), and OTP (over-temperature) protection.
