Medical Power Supply UES65CZ-SPA
Home Medical Power Supply UES65CZ-SPA Desktop style 65w medical 19V external AC DC switching power supply Complies with medical safety certification 2 MOPP isolation protection
Meets communication and medical safety certification
2 MOPP isolation protection
Leakage current ≤ 100μA
DOE efficiency level VI
Standby power consumption ≤ 0.15W
Working altitude 5000 meters
5V to 20V output, up to 60W
Support USB PD3.0 fast charging protocol
The UES60LCP-SPC is a robust 60W AC-DC switching power supply, a wall plug external 12V power supply, designed for medical applications. With a universal 90- 264VAC input, it supports 5V, 9v, 12v, 15v and 20V outputs and USB PD3.0 fast charging. Compliant with IEC 60601-1 and IEC 62368-1power supply, it ensures 2 x MOPP isolation, ≤100µA leakage current, and DOE Level VI efficiency with ≤0.15W standby power. Reliable up to 5,000m altitude, it’s perfect for medical devices and portable electronics, delivering safe, efficient power globally. This power supply is 20V, applicable in dental LED light curing machines, muscle rehabilitation devices, physical therapy electrical stimulation devices, bone density testing devices, urine analyzer, and handheld endoscopes.
Safety Standards – IEC60601,ES60601,EN60601
Safety Approvals – BSMI, CB, CCC, CE, cULus, FCC, KC, NOM, NRTL, PSE, RCM, TUV-GS, TUV-Mark
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UES60LCP-200300SPC | 60.0 | 90-264 | 5.0 | 0.01-3.00 | 0~+40 | BSMI, CB, CCC, CE, cULus, FCC, KC, NOM, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES60LCP-200300SPC | 60.0 | 90-264 | 9.0 | 0.01-3.00 | 0~+40 | BSMI, CB, CCC, CE, cULus, FCC, KC, NOM, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES60LCP-200300SPC | 60.0 | 90-264 | 12.0 | 0.01-3.00 | 0~+40 | BSMI, CB, CCC, CE, cULus, FCC, KC, NOM, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES60LCP-200300SPC | 60.0 | 90-264 | 15.0 | 0.01-3.00 | 0~+40 | BSMI, CB, CCC, CE, cULus, FCC, KC, NOM, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
| UES60LCP-200300SPC | 60.0 | 90-264 | 20.0 | 0.01-3.00 | 0~+40 | BSMI, CB, CCC, CE, cULus, FCC, KC, NOM, NRTL, PSE, RCM, TUV-GS, TUV-Mark |
It supports 5V, 9V, 12V, 15V, and 20V outputs.
It is suitable for patient monitors, CPAP machines, portable ultrasound, nebulizers, and diagnostic tools.
Yes, it can comply with medical safety standards such as IEC 60601-1.
The maximum output is 60 watts.
Yes, we offer multiple DC plug options to match different medical equipment.
Yes, it features a fanless design for silent operation, ideal for clinical environments.
Absolutely. Its compact and external design suits mobile setups.
It includes over-voltage, over-current, short-circuit, and thermal protection.
It supports a wide input range of 100–240V AC, suitable for global use.
Yes, we offer OEM/ODM services including cable and connector customization.
