Medical Power Supply UES65CZ-SPA
Home Medical Power Supply UES65CZ-SPA Desktop style 65w medical 19V external AC DC switching power supply Complies with medical safety certification 2 MOPP isolation protection
Compliant with medical safety certification
2 MOPP isolation protection
Leakage current ≤ 10μA
DOE efficiency level VI
Standby power consumption ≤ 0.21W
Working altitude 5000 meters
Gallium nitride technology
The UES60L1-SPAC is a compact 60W wall plug adapter optimized for medical applications. Featuring a 180-264VAC input and 24V output at 2.5A, it leverages GaN technology for high efficiency. Certified to IEC 60601-1, it ensures 2 x MOPP isolation class 2power supply adapter, ≤100µA touch current, and DOE Level VI efficiency with ≤0.21W standby power. With IP20 protection, customizable DC connectors, and reliable operation up to 5,000m altitude, this is 24V switching power supply for medical devices like dental LED light curing machine, muscle rehabilitation device, physical therapy electrical stimulation device, bone density testing device, urine analyzer, handheld endoscope, delivering safe, efficient, and robust power.
Safety Standards – IEC60601
Safety Approvals – TUV/CB,CQC
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Safety Standards |
|---|---|---|---|---|---|---|
| UES60L1-SPAC | 60.0 | 180-264 | 24.0 | 0.01-2.50 | 0~+30 | TUV/CB,CQC |
It supports 24V outputs.
It is suitable for patient monitors, CPAP machines, portable ultrasound, nebulizers, and diagnostic tools.
Yes, it can comply with medical safety standards such as IEC 60601-1.
The maximum output is 60 watts.
Yes, we offer multiple DC plug options to match different medical equipment.
Yes, it features a fanless design for silent operation, ideal for clinical environments.
Absolutely. Its compact and external design suits mobile setups.
It includes over-voltage, over-current, short-circuit, and thermal protection.
It supports a wide input range of 100–240V AC, suitable for global use.
Yes, we offer OEM/ODM services including cable and connector customization.
