ITE Power Adapter UE020LCP/UE020LCP1
Home ITE Adapter UE020LCP/UE020LCP1 LED Driver 20W Wall Plug External Switching Power Supply Wide range of AC input voltage 90- 264VAC Protections against: short circuit/over
AC input voltage range 90- 264VAC
Protections against: short circuit/ over current/ over voltage
High efficiency, ultra-low standby power consumption
Energy efficiency level Vl
SupportPD3.0, QC3.0 ,QC2.0 ,PPS
The UES45LCP-SPC is a 45W wall plug power supply for ITE use. With a 90- 264VAC input, it supports 5V, 9V, 12V, 15V and 20V outputs and USB PD3.0, QC3.0, QC2.0, and PPS fast charging. Certified to IEC 60601-1 and IEC 62368-1, it ensures 2 x MOPP isolation, ≤100µA leakage current, and DOE Level VI efficiency with ≤0.1W standby power. Compact (125g) with fixed or interchangeable plugs, it’s ideal for portable medical devices and electronics, offering safe, efficient power up to 5,000m altitude. It is suitable for Tablet computers, wireless routers, network storage (NAS), projector, portable air purifier, and barcode scanners.
Safety Standards – EN62368,
Safety Approvals – CCC
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UES45LCP-SPC | 45.0 | 80-264 | 5.0 | 0.01-3.00 | -20~+50 | CB, TUV-Mark |
| UES45LCP-SPC | 45.0 | 80-264 | 9.0 | 0.01-3.00 | -20~+50 | CB, TUV-Mark |
| UES45LCP-SPC | 45.0 | 80-264 | 12.0 | 0.01-3.00 | -20~+50 | CB, TUV-Mark |
| UES45LCP-SPC | 45.0 | 80-264 | 15.0 | 0.01-3.00 | -20~+50 | CB, TUV-Mark |
| UES45LCP-SPC | 45.0 | 80-264 | 20.0 | 0.01-2.25 | -20~+50 | CB, TUV-Mark |
This adapter supports multiple output voltages: 5V, 9V, 12V, 15V, and 20V, with a maximum power of 45W.
Yes, it supports USB Power Delivery (PD) protocol.
It's suitable for laptops, tablets, wireless routers, NAS, smart speakers, and other IT equipment.
The maximum output power is 45 watts.
Yes, it includes OCP (Over-Current Protection), OVP (Over-Voltage Protection), and SCP (Short-Circuit Protection).
Yes, models with UL, CE, PSE, and FCC certifications are available upon request.
Yes, DC plug type, USB-C, and cable length can all be customized.
Yes, it supports 100-240V AC input, suitable for worldwide use.
Yes, it complies with IEC/EN/UL 62368-1 and is classified as an ITE adapter.
Operating: 0°C to +40°C; Storage: -20°C to +85°C.
