ITE Power Adapter UES100B-SPCZ/UES100C-SPCZ
- Home
- ITE Power Adapter UES100B-SPCZ/UES100C-SPCZ
ITE Adapter UES100B-SPCZ/UES100C-SPCZ
Medical &l.T.E.safety approvals
2 MOPP input-to-output isolation
Leakage current ≤ 100uA
Energy efficiency level V
≤0.15W standby power
5V/9V/12V115V120V outputs, up to 100w
Up to 5,000m operating altitude
Interchangeable plug design
MeetUSB PD3.1 & PD3.0 & QC4.0+ & QC3.0 & QC2.0 fast charge agreement
DESCRIPTION
The UES100B-SPCZ and UES100C-SPCZ are high-efficiency 100W I.T.E. desktop power adapters, delivering 5V to 20V outputs with USB PD3.1, PD3.0, QC4.0+, QC3.0, and QC2.0 fast charging support. With a universal 80- 264VAC input and GaN technology, they ensure DOE Level VI efficiency and ≤0.15W standby power. Certified to IEC 62368-1, they offer robust safety, IP42 protection, and reliable operation up to 5,000m altitude. With multiple AC inlet options, they’re ideal for Laptops and Ultrabooks, Test instruments, Professional camera gear, external displays, network devices, and USB-C hubs, providing versatile, safe, and energy-efficient power globally.
Safety&Compliance
Safety Standards – EN62368,
Safety Approvals – CE
| Model Number | Power(W) | Input Voltage Range(VDC) | Output Voltage(VDC) | Output Current(A) | Operating Temperature Range(℃) | Efficiency Standards |
|---|---|---|---|---|---|---|
| UES100B-SPCZ/UES100C-SPCZ | 100.0 | 80-264 | 5.0 | 0.01-3.00 | 0~+40 | CB, CE, TUV-Mark, UL |
| UES100B-SPCZ/UES100C-SPCZ | 100.0 | 80-264 | 9.0 | 0.01-3.00 | 0~+40 | CB, CE, TUV-Mark, UL |
| UES100B-SPCZ/UES100C-SPCZ | 100.0 | 80-264 | 12.0 | 0.01-3.00 | 0~+40 | CB, CE, TUV-Mark, UL |
| UES100B-SPCZ/UES100C-SPCZ | 100.0 | 80-264 | 15.0 | 0.01-3.00 | 0~+40 | CB, CE, TUV-Mark, UL |
| UES100B-SPCZ/UES100C-SPCZ | 100.0 | 80-264 | 20.0 | 0.01-5.00 | 0~+40 | CB, CE, TUV-Mark, UL |
RELATED APPLICATIONS
POPULAR QUESTIONS
If it uses USB-C PD (Power Delivery), the connected device negotiates the correct voltage automatically. For programmable adapters, DIP switches or software control may be used.
Yes. If the device supports USB-C PD or requires lower voltage (like 5V or 9V), the adapter intelligently adjusts output to match it.
Typically certified with CE, UL, FCC, RoHS, and compliant with IEC 62368 and DOE Level VI or ERP energy efficiency standards.
If it has multiple ports or a smart hub design, yes. Otherwise, a single-port adapter can only power one device at a time.
No. The adapter uses a smart protocol (PD) to negotiate the correct voltage. It only outputs what the connected device requests.
Yes, if the adapter allows manual or negotiated 12V output, and the display accepts 12V DC with proper current draw (≤3A).
You need a USB-C to USB-C E-marked cable rated for 5A (100W) to enable full 20V/5A output.
The wall-plug version is intended for portable or desktop use. For fixed installations, consider a desktop or industrial version.
The adapter will limit the output to 100W. Some devices may charge slowly or display a warning. Always use devices within rated specs.
Most 100W wall-plug adapters are fanless with efficient thermal design. High-load operation may cause it to get warm, but it's designed to handle that.
