Healthcare devices need reliable power. Quankang’s UE15 series delivers this with cutting-edge design meeting strict medical standards.

Quankang’s UE15-150100SPA-OP is a 15W open-frame medical power adapter certified to IEC 60601-1 standards, offering 85% efficiency for safer, more sustainable healthcare operations (max power draw: 0.1W).

What makes this medical adapter truly stand out? Let’s examine its game-changing features and real-world benefits.

Why Choose an Open-Frame Design for Medical Power Solutions?

Space matters in medical equipment. Our open-frame adapter solves this challenge perfectly.

The UE15’s compact board-mount design saves 40% space compared to enclosed adapters while maintaining full safety compliance, making it ideal for portable medical devices.

Key Benefits of Open-Frame Design

1. Space Efficiency

   • Dimensions: 76×52×28mm
   • Fits in tight device compartments
   • Enables smaller medical equipment designs

2. Thermal Performance

3. Installation Flexibility
   • Multiple mounting options
   • Compatible with various PCB layouts
   • No external casing required

This design approach gives medical device manufacturers more freedom in product development while meeting rigorous safety requirements.

How Does IEC 60601-1 Certification Protect Patients?

Patient safety can’t be compromised. Our adapters exceed international protection standards.

The UE15 series achieves 2 x MOPP (Means of Patient Protection) certification, providing double insulation against electrical hazards in critical care environments.

Understanding Medical Power Safety

The IEC 60601-1 3rd Edition standard requires:

Electrical Safety Measures

• Reinforced insulation
• Leakage current <100μA
• 4,000V AC dielectric strength

Critical Protections Incorporated

1. Over-voltage protection
2. Short-circuit protection
3. Over-temperature shutdown

We implement these through:

1. Component Selection

   • Medical-grade capacitors
   • Reinforced isolation transformers

2. Design Features

   • Creepage distance: ≥8mm
   • Clearance distance: ≥5mm

These measures ensure continuous operation even during power fluctuations, crucial for life-support equipment.

What Energy Savings Can Healthcare Facilities Expect?

Hospitals waste thousands on idle power. Our solution cuts this cost dramatically.

The UE15’s <0.1W no-load consumption and 85% efficiency can reduce hospital energy bills by up to 30% compared to conventional medical power supplies.

Calculating the Efficiency Advantage

Energy Savings Breakdown

Sustainability Benefits

1. Lower carbon footprint
2. Reduced heat generation
3. Extended equipment lifespan

For a 500-bed hospital:

• Potential annual savings: $18,000-$25,000
• CO2 reduction equivalent to planting 800 trees

Conclusion

Quankang’s UE15 series delivers safer, more efficient power for medical devices while cutting costs and supporting environmental goals.
